Description
|
| Camera | ||
| Image Sensor | 1/3″ Progressive Scan CMOS | |
| Angle Adjustment | Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° | |
| Max. Resolution | 2560 × 1440 | |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR | |
| Shutter Time | 1/3 s to 1/100,000 s | |
| Day & Night | IR cut filter | |
| Lens | ||
| Lens Type | Fixed focal lens, 2.8 and 4 mm optional | |
| Focal Length & FOV | 2.8 mm, horizontal FOV 98° | |
| Lens Mount | M12 | |
| Illuminator | ||
| Supplement Light Type | IR,White Light | |
| Supplement Light Range | Up to 30 m | |
| Image | ||
| Image Settings | Rotate mode,saturation,brightness,contrast | |
| Day/Night Mode | Day,Night,Auto,Schedule | |
| Wide Dynamic Range (WDR) | 120 dB | |
| Image Enhancement | BLC,HLC,3D DNR | |
| Interface Eelectrical | ||
| Video Output | 50 Hz: 20 fps (2560 × 1440) | |
| General Information | ||
| Dimension | 170.8 mm × 66 mm × 69.1 mm | |
| Weight | Approx. 270 g (0.6 lb.) | |
| Operating Condition | -30 °C to 60 °C (-22 °F to 140 °F) | |
| Language | English, Ukrainian | |
| Power Supply | 12 VDC ± 25%, 0.4 A, max. 5 W,Ø5.5 mm | |
