Description
**Camera**
* **Image Sensor:** 1/2.8″ progressive scan CMOS
* **Minimum Illumination:** Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON)
* **Shutter Speed:** 1/3 s to 1/100,000 s
* **Angle Adjustment:** Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
* **Slow Shutter:** Yes
* **Auto-Iris:** No
* **Day & Night:** IR cut filter
* **Digital Noise Reduction:** 3D DNR
* **WDR:** DWDR
**Lens**
* **Focal Length:** 2.8 mm, 4 mm
* **Aperture:** F2.0
* **Focus:** Fixed
* **FOV:**
* 2.8 mm: Horizontal FOV 114.8°, Vertical FOV 62°, Diagonal FOV 135.5°
* 4 mm: Horizontal FOV 86°, Vertical FOV 46.5°, Diagonal FOV 102.5°
* **Lens Mount:** M12
**General**
* **Storage Conditions:** -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
* **Power Supply:** 12 VDC ± 25%, 5.5 mm coaxial power plug; PoE (802.3af, class 3)
* **Power Consumption:**
* 12 VDC: 0.3 A, max 3.5 W
* PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 4.5 W
* **Ingress Protection:** IP67
* **Dimensions:**
* Camera: Ø 110 mm × 93.2 mm (4.3″ × 3.7″)
* With package: 150 mm × 150 mm × 141 mm (5.9″ × 5.9″ × 5.6″)
* **Material:** Camera body: metal, bottom base: plastic
* **Weight:** Approx. 360 g (0.8 lb)
