Description
Biometric and Card-Based Access Control
Advanced Access Control Functions
Flexible Communication Options
The ZKTeco inBio260 is ideal for secure access control in:
"ZKTeco inBio260 is reliable and easy to use. It improved our office security and the support team was very helpful. Highly recommended!" — Rahim Uddin, Dhaka
Specifications
| Attribute / Feature | Specification Details |
| Number of doors controller | 2 Door |
| Numbers of readers supported | 8(4 RS-485 Reader, 4 26-bit wiegand reader) |
| Types of readers supported | 26-bit Wiegand and RS485 FR Series Reader |
| Number of Inputs | 6( 2 Exit Button, 2 Door Status, 2 AUX) 4 (2-Form C Relay for Lock and 2- |
| Number of Outputs | Form C Relay for Aux Output) |
| Card holders Capacity | 30,000 |
| Fingerprint Capacity | 3,000 ( optional 20,000) |
| Log Events Capacity | 100,000 |
| Communication | TCP/IP |
| Package Dimension | 350(L)×90(H)×300(W)mm |
| Package Weight | 3.6kg |
| CPU | 32 bit 400MHz CPU |
| RAM | 32M |
| Flash Memory | 128M |
| Power | 9.6V-14.4V DC |
| Operating Temp | 0-45 °C |
| Operating Humidity | 20% to 80% |
